Highlights
- Dual UHD 4K Scaler
- Multi-Scaler Video Signal Converter
- 12G-SDI, HDMI 2.0, and Fiber In/Out
- LC Fiber Single Mode
- 2x2 Matrix Dual Input & Output
- Set Individual SDI and HDMI Resolutions
- Front OLED Display
- Analog Audio Muxing and De-Muxing
Digital Forecast UHD X_MC 12G-SDI/HDMI/Fiber 2.0 Multi-Scaler Converter – 4K UHD Video Scaling & Signal Conversion
SKU:
DF-UHD X_MC
MFR: UHD X_MC
Regular price
$978.00
Ships in 2-4 Weeks
Free Expedited Shipping
Secure payment
Manufacturer Warranty
Authorized Dealer
23
Digital Forecast UHD X_MC 12G-SDI/HDMI/Fiber 2.0 Multi-Scaler Converter – 4K UHD Video Scaling & Signal Conversion
Description
The Digital Forecast UHD X_MC is the ultimate 12G cross converter with dual scaler that lets you convert HDMI 2.0 and 12G SDI signals at the same time. With its built-in dual scaler, you can customize the resolution for both the 12G SDI and HDMI 2.0 outputs to suit your specific needs. The product also features a front OLED display.
Features:
- 1 x HDMI 2.0 Input, 1 x 12G SDI Input, 1 x 12G SDI Thru Output, 1 x 12G Optic Input
- 1 x HDMI 2.0 Output, 2 x 12G SDI Outputs, 1 x 12G Optic Output
- Standard SDI (HD, 3G, 6G, 12G) format supported
- Standard HDMI (Max 4096x2160) format supported
- Analog Audio MUX/DMX supported
- Convenient setting support through Front OLED Display
- Dual UHD 4K Scaler (SDI/HDMI Output can be set individually)
Specifications
Digital Forecast UHD X_MC 12G-SDI/HDMI/Fiber 2.0 Multi-Scaler Converter – 4K UHD Video Scaling & Signal Conversion Specifications
Reviews
What's included
Included on Digital Forecast UHD X_MC 12G-SDI/HDMI/Fiber 2.0 Multi-Scaler Converter – 4K UHD Video Scaling & Signal Conversion
Recommended Products
Recently Viewed Products
| Product Specifications | |
|---|---|
Video Inputs |
|
Audio Inputs |
|
Video Outputs |
|
Audio Outputs |
|
Video Standards |
|
| Physical / Environmental Specifications | |
Dimension |
|
Environment |
|
Warranty |
|
UPC / GTIN |
704006295100
|
